Adding a leader line mapnote

Step:

1. Select a mapnote layer in the target layer, and click add and select horizontal mapnote from the drop-down menu.

2. Click the map window to set the position of leader line, and then click the map window again to set the position of the added mapnote. The distance and angle of the lead line are decided by the first position and second position.

3. The EditBox pops up and you can enter the text string and check text symbology.

4. Click OK.

To modify the added mapnote, please refer the editing operation chapter.
